Product Summary

The A6351A is a hybrid IC with a built-in power MOSFET and a controller IC, designed for fly-back converter type SMPS(Switching Mode Power Supply) applications, packaged into DIP8, applicable for PRC operation only for small power SMPS. The A6351A realizes downsizing and standardizing of a power supply system reducing external components count and simplifying the circuit designs. PRC is abbreviation of Pulse Ratio Control (On-width control with fixed OFF-time).

Parametrics

A6351A absolute maximum ratings: (1)Drain Current Idpeak: 2.36 A; (2)Maximum Switching Current IDMAX: 2.36 A; (3)Avalanche Energy Capacity EAS: 56 mJ; (4)Voltage supply to Control Part VIN: 35 V; (5)OCP/FB Terminal Voltage Vth: 6 V; (6)Power Dissipation at MOSFET PD1: 1.35 W; (7)Power Dissipation at Control part(MIC) PD2: 0.14 W; (8)Internal Frame Temp. in operation TF: -20~+125 ℃; (9)Operating ambient temp. Top: -20~+125 ℃; (10)Storage temp. Tstg: -40~+125 ℃; (11)Channel temp. Tch: +150 ℃.

Features

A6351A features: (1)Small sized 8-pin DIP type full molded package, optimum IC for low-height SMPS; (2)Oscillator is incorporated in the monolithic control IC with adopting On-Chip-Trimming technology; (3)Small temperature characteristics variation by adopting a comparator compensated for temperature in the control part; (4)Low start-up circuit current(50μA max); (5)Built-in Active Low-Pass Filter for stabilizing the operation at light load; (6)Avalanche energy guaranteed MOSFET with high VDSS.

Diagrams

<IMG alt="A6351A diagram" src="http://www.seekic.com/uploadfile/ic-mfg/2012832215399.jpg" border=0>
