Product Summary

The AD7510DI,AD7511DA and AD7512DI are a family of latch proof dielectrically isolatcd CMOS switches featuring over-voltage protection up to ±25V above the power supplies.These bebefits are obtained without sacrificing the low"ON"resstance(75Ω)or low leakager current(500pA),the main features of an analog switch.

The ad7510DI and AD7511DI consist of four independent SPST analog switches package in eother a 16-pin DIP or a 20-terminal surface mount package.Ther differ only in that the digital control logic is inverted.The AD7512DI has two independet SPDT switches packaged either in a 14-pin DIP or a 20-terminal surface mount package.

Very low power dissipation,overvoltage protection and TTL/CMOS direct interfacing,are achieved by combing a unique circuit design and a dielectrically isolated CMOS process.Silicon nitride passivation ensures long term stability while monolithic construction provides reliability.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AD7510DIJN
AD7510DIJN

IC SWITCH QUAD SPST 16DIP
Data Sheet
0-25: $8.48
AD7510DIJNZ
AD7510DIJNZ

IC SWITCH QUAD SPST 16DIP
Data Sheet
0-1: $8.93
1-25: $7.51
25-100: $6.90
100-250: $6.29
250-500: $5.89
500-1000: $5.41
AD7510DIJP
AD7510DIJP

IC SWITCH QUAD SPST 20PLCC
Data Sheet
0-49: $8.09
AD7510DIJQ
AD7510DIJQ

IC SWITCH QUAD SPST 16CDIP
Data Sheet
Negotiable
AD7510DIKN
AD7510DIKN

IC SWITCH QUAD SPST 16DIP
Data Sheet
Negotiable
AD7510DIKNZ
AD7510DIKNZ

IC SWITCH QUAD SPST 16DIP
Data Sheet
0-1: $10.54
1-25: $8.86
25-100: $8.14
100-250: $7.42
250-500: $6.95
500-1000: $6.39
AD7510DIKP
AD7510DIKP

IC SWITCH QUAD SPST 20PLCC
Data Sheet
0-49: $9.19
AD7510DIKPZ
AD7510DIKPZ

IC SWITCH QUAD SPST 20PLCC
Data Sheet
0-49: $9.89
