The BSM15GP120 is a IGBT-Module.
Parametrics
Absolute maximum ratings: (1)repetitive peak reverse voltage: 1600 V; (2)RMS forward current per chip: 40 A; (3)DC forward current: 15 A at TC = 80℃ ; (4)surge forward current: 300 A at tP = 10 ms, Tvj = 25℃, 230 A at tP = 10 ms, Tvj = 150℃; (5)I2t - value: 450 A2s at tP = 10 ms, Tvj = 25℃, 260 A2s at tP = 10 ms, Tvj = 150℃.
Features
Features: (1)forward voltage: 0.95 V typ and 1 V max; (2)threshold voltage: 0.8 V max; (3)slope resistance: 10.5 mΩ; (4)reverse current: 2mA; (5)Modul Leitungswiderstand, Anschlüsse-Chip lead resistance, terminals-chip: 8 mΩ.
