LM343H

3-Channel, Constant Current LED Driver, 5V to 36V, TSSOP-28, LM343H

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~0.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.10~0.20

PartNumber:: LM343H

Brand:: National Semiconductor - NS | Pack: TO | D/C: 01+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Amanda's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-04-25

From Other Seller

Part Number:LM343H
US $0.10 - 0.20
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
ad7716ap

US $1.13 - 1.13 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LM343H is a 3-channel linear current controller combined with a boost switching controller ideal for driving LED back-light panels in space critical applications. The LM343H drives 3 external NPN transistors or MOSFETs to deliver high accuracy constant current to 3 LED strings. Output current is adjustable to drive strings in excess of 200 mA. The applications of the LM343H are Automotive Infotainment Displays, Small to Medium Format Displays.

Parametrics

LM343H absolute maximum ratings: (1)Voltages from the indicated pins to SGND: VIN:-0.3V to 37V, EN:-0.3V to 10V, DIM:-0.3V to 7V, MODE/F:-0.3V to 7V, REFIN:-0.3V to 7V, THM:-0.3V to 7V, DLY:-0.3V to 7V, SNSx:-0.3V to 7V, NDRVx:-0.3V to 7V, CFB:-0.3V to 7V, SC:-0.3V to 40V, AFB:-0.3V to 7V, CS:-0.3V to 7V, VCC:-0.3V to 7V; (2)Storage Temperature -65℃ to +150℃; (3)ESD Rating: Human Body Model:2 kV.

Features

LM343H features: (1)LM3431Q/LM3431AQ are Automotive Grade products that are AEC-Q100 grade 1 qualified (-40℃ to 125℃ operating junction temperature); (2)3-channel programmable LED current; (3)High accuracy linear current regulation; (4)Analog and digital PWM dimming control; (5)Up to 25kHz dimming frequency; (6)>100:1 contrast ratio; (7)Integrated Boost controller; (8)5V to 36V input voltage range; (9)Adjustable switching frequency up to 1MHz; (10)LED short and open protection; (11)Selectable fault shutdown or automatic restart; (12)Programmable fault delay; (13)Programmable cycle by cycle current limit; (14)Output Over Voltage Protection; (15)No Audible Noise; (16)Enable pin; (17)LED Over-Temperature shutdown input; (18)Thermal Shutdown; (19)TSSOP-28 exposed pad package.
