Product Summary

The E28F800B5T-90 is a smart 5 boot block flash memory. It provides pinout-compatible flash memories at the 2-, 4-, and 8-Mbit densities.

Parametrics

E28F800B5T-90 absolute maximum ratings: (1)Commercial Operating Temperature During Read/Erase/Program: 0 ℃ to +70 ℃, Temperature Under Bias: –10 ℃ to +80 ℃; (2)Extended Operating Temperature During Read/Erase/Program: –40 ℃ to +85 ℃, Temperature Under Bias: –40 ℃ to +85 ℃; (3)Storage Temperature: –65 ℃ to +125 ℃; (4)Voltage on Any Pin with Respect to GND: –2.0 V to +7.0 V; (5)Voltage on Pin RP# or Pin A9 with Respect to GND: –2.0 V to +13.5 V; (6)VPP Program Voltage with Respect to GND during Block Erase and Word/Byte Program: –2.0 V to +14.0 V; (7)VCC Supply Voltage with Respect to GND: –2.0 V to +7.0 V; (8)Output Short Circuit Current: 100 mA.

Features

E28F800B5T-90 features: (1)SmartVoltage Technology; (2)Very High-Performance Read; (3)Low Power Consumption; (4)Optimized Array Blocking Architecture; (5)Extended Temperature Operation: –40 to +85℃; (6)Industry-Standard Packaging: 40, 48-Lead TSOP, 44-Lead PSOP; (7)SRAM-Compatible Write Interface; (8)Reset/Deep Power-Down Input-Provides Low-Power Mode and Reset for Boot Operations; (10)Pinout Compatible 2, 4, and 8 Mbit.

Diagrams

<IMG alt="E28F800B5T-90 diagram" src="http://www.seekic.com/uploadfile/ic-mfg/20128322451846.jpg" border=0>
