Product Summary
The IDT7201LA25SOI is a dual-port memory that load and empty data on a first-in/first-out basis. The device uses Full and Empty flags to prevent data overflow and underflow and expansion logic to allow for unlimited expansion capability in both word size and depth. The IDT7201LA25SOI utilizes a 9-bit wide data array to allow for control and parity bits at the user’s option. This feature is especially useful in data communications applications where it is necessary to use a parity bit for transmission/reception error checking. The IDT7201LA25SOI is designed for those applications requiring asynchronous and simultaneous read/writes in multiprocessing and rate buffer applications.
Parametrics
IDT7201LA25SOI absolute maximum ratings: (1)VTERM Terminal Voltage with Respect to GND: –0.5 to +7.0 V; (2)TSTG Storage Temperature: –55 to +125 ℃; (3)IOUT DC Output Current: –50 to +50 mA.
Features
IDT7201LA25SOI features: (1)Ultra high speed-2ns access time; (2)Asynchronous and simultaneous read and write; (3)Fully expandable by both word depth and/or bit width; (4)Pin and functionally compatible with 720X family; (5)Status Flags: Empty, Half-Full, Full; (6)Auto-retransmit capability; (7)High-performance CEMOS technology; (8)Military product compliant to MIL-STD-883, Class B; (9)Standard Military Drawing #5962-87531, 5962-89666, 5962-89863 and 5962-89536 are listed on this function; (10)Industrial temperature range (-40 to +85℃) is available (plastic packages only).
Diagrams
<IMG alt="IDT7201LA25SOI block diagram" src="http://www.seekic.com/uploadfile/ic-mfg/20128322254568.jpg" border=0>
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 IDT7201LA25SOI |
|
IC MEM FIFO 512X9 25NS 28-SOIC |
Data Sheet |
|
|
||||||
|
IDT7201LA25SOI8 |
|
IC MEM FIFO 512X9 25NS 28-SOIC |
Data Sheet |
|
|
||||||
