Product Summary

The RZQ050P01TR is a 1.5V drive pch MOSFET. The RZQ050P01TR is specified in this document are intended to be used with general-use electronic equipment or devices (such as audio visual equipment, office-automation equipment, communication devices, electronic appliances and amusement devices). The RZQ050P01TR is not designed to be radiation tolerant.

Parametrics

RZQ050P01TR absolute maximum ratings: (1)Drain-source voltage VDSS: －12V; (2)Gate-source voltage VGSS: ±10V; (3)Drain current Continuous ID: ±5A; (4)Drain current Pulsed ISP1: ±20A; (5)Source current (Body diode)Continuous IS: －1A; (6)Source current (Body diode)Pulsed ISP1: －20A; (7)Total power dissipation PD2: 1.25W; (8)Channel temperature Tch: 150℃; (9)Range of Storage temperature Tstg: －55 to +150℃.

Features

RZQ050P01TR features: (1)Low on-resistance;(2)High power package;(3)Low voltage drive.(1.5V).

Diagrams

RZQ050P01TR pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
RZQ050P01TR
RZQ050P01TR
ROHM Semiconductor
MOSFET Med Pwr, Sw MOSFET P Chan, -12V, -5A
Data Sheet
0-1: $0.44
1-25: $0.32
25-100: $0.25
100-250: $0.19
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
RZQ045P01TR
RZQ045P01TR
ROHM Semiconductor
MOSFET P Chan-12V+/-4.5A 1.5V Drive
Data Sheet
0-1: $0.45
1-25: $0.35
25-100: $0.27
100-250: $0.17
RZQ050P01TR
RZQ050P01TR
ROHM Semiconductor
MOSFET Med Pwr, Sw MOSFET P Chan, -12V, -5A
Data Sheet
0-1: $0.44
1-25: $0.32
25-100: $0.25
100-250: $0.19
