Product Summary

The SP14Q002-A1 is a 5.7 inch LCD display.

Parametrics

SP14Q002-A1 absolute maximum ratings: (1)POWER SUPPLY FOR LOGIC VDD-VSS: 6 V; (2)POWER SUPPLY FOR LC DRIVING VDD-VEE: 27.5 V; (3)INPUT SIGNAL VOLTAGE Vi: -0.3 VDD+0.3 V NOTE 1; (4)INPUT SIGNAL CURRENT Ii: 1 A; (5)STATIC ELECTRICITY VESD0: ±100 V NOTE 2,3,4.

Features

SP14Q002-A1 features: (1)PART NAME SP14Q002-A1; (2)MODULE SIZE 167.0(W)mm×109.0(H)mm×10.0 (D)mm (max.); (3)EFFECTIVE DISPLAY AREA 120 mm min×89 mm min; (4)DOT SIZE 0.345(W)min.×0.345(H)min; (5)DOT PITCH 0.360(W)mm×0.360(H)mm; (6)DOT NUMBER 320 (W)×240 (H); (7)DUTY RATIO 1/240; (8)VIEWING DIRECTION 6 O CLOCK; (9)BACK LIGHT COLD CATHODE FLUORESCENT LAMP.

Diagrams

SP14Q002-A1 block diagram
