SP232EENTR

high performance RS-232 line drivers/receiver, 11.0V, 375mW, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.80~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.80~1.00

PartNumber:: SP232EENTR

Brand:: Sipex Corporation - Exar | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Amanda's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-08

From Other Seller

Part Number:SP232EENTR
US $0.80 - 1.00
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
2DI75D-050A

US $16.00 - 30.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SP232EENTR is a high performance RS-232 line drivers/receiver that meet the specifications of RS－232 and V.28 serial protocols with enhanced ESD performance. The ESD tolerance has been improved on these devices to over ±15KV for both Human Body Model and IEC1000－4－2 Air Discharge Method. The SP232EENTR is pin－to－pin compatible with Sipex SP232EENTR as well as popular industry standards. As with the initial versions, the SP232EENTR features at least 120Kbps data rate under load, 0.1F charge pump capacitors, and overall ruggedness for commercial applications. This family also features Sipex BiCMOS design allowing low power operation without sacrificing performance. The series is available in plastic and ceramic DIP and SOIC packages operating over the commercial, industrial and military temperature ranges.

Parametrics

SP232EENTR absolute maximum ratings: (1)Vcc : +6V; (2)V+: (Vcc－0.3V)to +11.0V; (3)V－: －11.0V; (4)Input Voltages TIN : －0.3 to (Vcc +0.3V), RIN: ±15V; (5)Output Voltages TOUT : (V+, +0.3V)to (V－, －0.3V), ROUT:: －0.3V to (Vcc +0.3V); (6)Short Circuit Duration TOUT : Continuous; (7)Power Dissipation CERDIP : 675mW (derate 9.5mW/°C above +70°C); (8)Plastic DIP: 375mW.

Features

SP232EENTR features: (1)Operates from Single +5V Power Supply; (2)Meets All RS-232D and ITU V.28 Specifications; (3)Operates with 0.1μF to 10μF Capacitors; (4)High Data Rate －120Kbps Under Load; (5)Low Power Shutdown ≤1μA (Typical); (6)3-State TTL/CMOS Receiver Outputs; (7)Low Power CMOS －3mA Operation; (8)Improved ESD Specifications: ±15kV Human Body Model, ±15kV IEC1000-4-2 Air Discharge, ±8kV IEC1000-4-2 Contact Discharge.
