Product Summary

The SX1276/77/78/79 transceivers feature the LoRaTM long
range modem that provides ultra-long range spread
spectrum communication and high interference immunity
whilst minimising current consumption.
Using Semtech’s patented LoRaTM modulation technique
SX1276/77/78/79 can achieve a sensitivity of over -148dBm
using a low cost crystal and bill of materials. The high
sensitivity combined with the integrated +20 dBm power
amplifier yields industry leading link budget making it
optimal for any application requiring range or robustness.
LoRaTM also provides significant advantages in both
blocking and selectivity over conventional modulation
techniques, solving the traditional design compromise
between
range,
interference
immunity
and
energy
consumption.
These devices also support high performance (G)FSK
modes for systems including WMBus, IEEE802.15.4g. The
SX1276/77/78/79
deliver
exceptional
phase
noise,
selectivity, receiver linearity and IIP3 for significantly lower
current consumption than competing devices.
