Product Summary

Designed to interface logic to a wide variety of highcurrent, high voltageloads, thesedeviceseach con-tain four NPN darlington switches delivering up to1.5 A with a specified minimum breakdown of 50 Vand a sustaining voltage of 35 V measured at 100mA. The ULN2064B, ULN2066B, ULN2068B andULN2070B contain integral suppression diodes forinductive loads have common emitters. TheULN2074B and ULN2076B feature isolated dar-lington pinouts and are intended for applicationssuch as emitter follower configurations.Inputsof theULN2064B, ULN2068B and ULN2074B are com-patible with popular 5 V logic families and theULN2066B and ULN2076B are compatible with 6-15 V CMOS and PMOS. Types ULN2068B andULN2070Binclude a predriver stageto reduceload-ing on the control logic.

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
ULN2074B
ULN2074B
STMicroelectronics
Transistors Darlington 1.5 Amp Quad Switch
Data Sheet
0-1: $1.50
1-10: $1.22
10-100: $1.08
100-250: $0.96
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
ULN2001
ULN2001
Other

Data Sheet
Negotiable
ULN2001A
ULN2001A
STMicroelectronics
Transistors Darlington Seven NPN Array
Data Sheet
0-1: $0.37
1-10: $0.32
10-100: $0.24
100-250: $0.21
ULN2001D
ULN2001D
Other

Data Sheet
Negotiable
ULN2001D1
ULN2001D1
STMicroelectronics
Transistors Darlington Seven NPN Array
Data Sheet
Negotiable
ULN2001D1013TR
ULN2001D1013TR
STMicroelectronics
Transistors Darlington Seven NPN Array
Data Sheet
0-1: $0.36
1-25: $0.26
25-100: $0.23
100-250: $0.20
ULN2002
ULN2002
Other

Data Sheet
Negotiable
