Product Summary
The DS1307 Serial Real Time Clock is a low power, full BCD clock/calendar plus 56 bytes of
nonvolatile SRAM. Address and data are transferred serially via a 2-wire bi-directional bus. The
clock/calendar provides seconds, minutes, hours, day, date, month, and year information. The end of the
month date is automatically adjusted for months with less than 31 days, including corrections for leap
year. The clock operates in either the 24-hour or 12-hour format with AM/PM indicator. The DS1307
has a built-in power sense circuit which detects power failures and automatically switches to the battery
supply.
Features
- Real time clock counts seconds, minutes,
- hours, date of the month, month, day of the
- week, and year with leap year compensation
- valid up to 2100
- 56 byte nonvolatile RAM for data storage
- 2-wire serial interface
- Programmable squarewave output signal
- Automatic power-fail detect and switch
- circuitry
- Consumes less than 500 nA in battery backup
- mode with oscillator running
- Optional industrial temperature range
- -40°C to +85°C
- Available in 8-pin DIP or SOIC
- Recognized by Underwriters Laboratory
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 DS1307Z |
Maxim Integrated Products |
Real Time Clock 64x8 Serial I2C RTC |
Data Sheet |
|
|
||||||||||||
|
DS1307Z/T&R |
Maxim Integrated Products |
Real Time Clock 64x8 Serial I2C RTC |
Data Sheet |
|
|
||||||||||||
 |
DS1307Z/T&R/C03 |
Maxim Integrated Products |
Real Time Clock |
Data Sheet |
Negotiable |
|
||||||||||||
 |
DS1307Z+ |
Maxim Integrated Products |
Real Time Clock 64x8 Serial I2C RTC |
Data Sheet |
|
|
||||||||||||
 |
DS1307Z+T&R |
Maxim Integrated Products |
Real Time Clock 64x8 Serial I2C RTC |
Data Sheet |
|
|
||||||||||||
|
DS1307Z+T&R/C01 |
Maxim Integrated Products |
Real Time Clock 64x8 Serial I2C RTC |
Data Sheet |
|
|
||||||||||||
|
DS1307Z+TR |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
|
DS1307ZN |
Maxim Integrated Products |
Real Time Clock 64x8 Serial I2C RTC |
Data Sheet |
|
|
||||||||||||
